FLY SKY FS IA6B RF 2.4GHz 6CH PPM output with iBus port receiver


The FLY SKY FS IA6B RF 2.4GHz 6CH PPM output with iBus port receiver works great with the FlySky FS-i6 Controller.

This compact 6 channel receiver is great for any model using up to 6 channels and, with a range exceeding 500 meters, it can be considered to be the full range for all but the most demanding of application. The receiver has end-on connectors to enable a neat installation in tight spaces.

This has FLY SKY FS IA6B RF 2.4GHz 6ch PPM output with iBus port receiver built in connectors which allows you to use any of the optional FlySky telemetry sensors. Dual antennas give the FS-iA6B excellent reception and interference rejection capability. With easy binding, compact dimensions, optional telemetry, and dual antennas.

Features :

  1. Transmitting Power: 20 dBm.
  2. 2.4G Mode: The second generation of an enhanced version of the automatic FM digital system.
  3. Model Type : Airplane / Glider / Helicopter
  4. Compatible Transmitter: Compatible with FS-i4, FS-i6, FS-i10, FS-GT2E, FS-GT2G etc.

Specifications :-

Model FS-iA6B
No. of Channels 6
No. of Band 140
Encoding GFSK.
RF Range 2.40552.475 GHz.
Rx Sensitivity (dBm) -105
Operating Voltage (VDC) 4.0 ~ 8.4V
i-Bus Interface Yes
Data Acquisition Interface Yes
Antenna Length (mm) 26
Video Format Supported NTSC/PAL
Color Black
Net weight (gm) 14.9
Dimensions (mm) LxWxH 47 x 26.2 x 15
